Note: In receive portion of C-band only, sidelobe envelope specified from 100l/D rather than 1°
Antenna Noise Temperature
5° Elevation
10° Elevation
20° Elevation
40° Elevation
55 K
45 K
38 K
36 K
62 K
52 K
45 K
43 K
70 K
60 K
55 K
45 K
60 K
51 K
47 K
47 K
Power Handling
1 kW
1 kW
100 kW
2 kW
Cross Polarization Isolation
On Axis
Within 1.0 dB Beamwidth
> 30 dB
> 27 dB
Rx >15.00 dB–Tx >17.70 dB
Rx >15.00 dB–Tx >17.70 dB
Rx >30.00 dB–Tx >35.00 dB
Rx >25.00 dB–Tx >26.00 dB
Rx >23.20 dB–Tx >18.80 dB
Rx >23.20 dB–Tx >18.80 dB
Note: Standard C-band Circular polarization in Tx-Band provides an axial ratio of 1.3 (XPD equivalence of 17.7 dB). Optional F-1 station feed available with axial ratio of 1.09 (XPD equivalence > 27.3 dB) in Tx band. Call the factory when specifying this option. X Band filters are available upon request.
Output Waveguide Interface Flange
Receive (Rx)
Transmit (Tx)
CPR 229 F
CPR 137 or Type N
CPR 229 F
CPR 137 or Type N
WR 75
WR 75
WR 112
WR 112
Reflector Material
Glass Fiber Reinforces Polyester SMC
Antenna Optics
Easy-to-Assemble, Four-piece, Offset Feed Prime Focus Design with 0.6 F/D Optics
Mast Pipe Size
10” Sch 80 Pipe (10.75” OD) 27.3 cm
Elevation Adjustment Range
12° to 90° or 0° to 15° for Polar Latitudes
Azimuth Adjustment Range
360° Continuous with +/- 35° Fine Adjustment
Wind Loading
Operational
Survival
50 mph (80 km/h)
125 MPH (201 Km/H)
Temperature
Operational
-40° to 140° F (-40° to 60° C)
Rain
Operational
1/2” (13 mm)/hr
Ice
Operational
--------------
Atmospheric Conditions
Salt, Pollutants and Contaminants as Encountered in Coastal and Industrial Areas
